Mobile Concrete Batching Plant

YHZS75Mobile Cement Batching Plant

Product description: YHZS75Mobile Cement Batching Plant Manufacturer,Concrete Mixing Plant Supplier of China
INQUIRY

Model	YHZS25	YHZS35	YHZS50	YHZS60	YHZS75	YHZS90
Theoretical productivity (m3/h)	25	25	50	60	75	90
Standard discharge height (m)	1.5-3.8	1.5-3.8	2.7-3.8	3.8	2.7-3.8	3.8
Working cycle time (s)	72	72	72	60	72	60
Total installed capacity (kw)	50	60	115	105	120	145
Model	JS500	JS500	JS1000	JS1000	JS1500	JS1500
Model	PLD1200	PLD1200	PLD1200	PLD1600	PLD2400	PLD2400
Air compressor model	1.0-7	1.0-7	1.0-7	1.5-7	1.0-7	1.8-7
Rated exhaust volume (m3/min)	1.67	1.67	1.67	1.67	1.85	1.67
Rated exhaust pressure (MPa)	0.8	0.8	0.8	0.8	0.8	0.8
Motor power (KW)	5.5	5.5	5.5	7.5	11	11

Product Advantages:

1.High Stability
Heavy-duty steel frame desigh,overall stability, spacious space,easy maintenance.

2.High performance of mixing
Mixer adopts twin-shaft concrete mixer,meets the mixing of various concrete.

3.High quality of belt
High stability belt,rubber coating drum,nylon core belt enable long service life.Forward roller is effectivelty antidebiating. The head of belt conveyor is equipped with a gauge cover,effectively preventing the material spilled.

4.High class configuration,stable quality,accurate weighing.
The main electrical components of mixer,weighing sensor and control system adopt world weill-known brands,with stable quality and accurate weighing.

5.High degree of automation,easy operation
The whole machine is controlled by computer,either automatically or manually,simple,easy to opearate. It can also store and print the reported data,providing great converience for production scheduling management.

Our Service:

Faster speed of response of service Modern transportation network of railway and aviation,make sure that all spare parts got delivered in time.

Apart from supplying only the best quality products, we also have available our technical and management solutions.
Our service teams always ready to provide expertise to you. Truemax is ready to provide you with a full range of services.

Best service effect to win your satisfaction and trust We continue to work for guests providing customized system solutions and provide best support and services.Because of the formidable technical team, we have provided high quality tour service to all guests.
